Micro Tiller
机型特点整理中。。。
3TGq-4e
Rated Output/RotarySpeed(kw/r/min) 3.9/3600 Displacement(ml) 212 Fuel Tank Capacity(L) 3.6 Driving Mode Gear Tilling Depth(cm) ≥10 Tilling Width(cm) 68 Blades Type 3.5-6 Package Dimensions(mm) 1300*560*680 Loading Quantity(20GP/40HQ) 51/108 G.W(kg) 75
SR1Z-135D
Rated Output/RotarySpeed(kw/r/min) 8.7/3600 Displacement(ml) 420 Fuel Tank Capacity(L) 6.5 Driving Mode Gear Transmission Tilling Depth(cm) ≥10 Tilling Width(cm) 135 Blades Type 4-5/40pcs Package Dimensions(mm) 1010*645*775 Loading Quantity(20GP/40HQ) 60/123 G.W(kg) 156.5
SR1Z-100
Rated Output/RotarySpeed(kw/r/min) 3.9/3600 Displacement(ml) 212 Fuel Tank Capacity(L) 3.6 Driving Mode Gear Tilling Depth(cm) ≥10 Tilling Width(cm) 100 Blades Type 3-4/24pcs Package Dimensions(mm) 885*520*660 Loading Quantity(20GP/40HQ) 84/230 G.W(kg) 115
SR1Z-75
Rated Output/RotarySpeed(kw/r/min) 3.9/3600 Displacement(ml) 212 Fuel Tank Capacity(L) 3.6 Driving Mode Chain and Belt Tilling Depth(cm) ≥10 Tilling Width(cm) 75 Blades Type 3-4/24pcs Package Dimensions(mm) 840*465*660 Loading Quantity(20GP/40HQ) 99/278 G.W(kg) 84
SR1Z-70
Rated Output/RotarySpeed(kw/r/min) 3.9/3600 Displacement(ml) 212 Fuel Tank Capacity(L) 3.1 Driving Mode Chain and Belt Tilling Depth(cm) ≥10 Tilling Width(cm) 70 Blades Type 3-4/24pcs Package Dimensions(mm) 685*410*795 Loading Quantity(20GP/40HQ) 132/270 G.W(kg) 67
SR1Z-50
Rated Output/RotarySpeed(kw/r/min) 3.9/3600 Displacement(ml) 212 Fuel Tank Capacity(L) 3.6 Driving Mode Chain and Belt Tilling Depth(cm) ≥10 Tilling Width(cm) 50 Blades Type 2-3/12pcs Package Dimensions(mm) 1200*530*820 Loading Quantity(20GP/40HQ) 40/123 G.W(kg) 87.4
SR1Z-40
Rated Output/RotarySpeed(kw/r/min) 1.6/3600 Displacement(ml) 98.5 Fuel Tank Capacity(L) 1.6 Driving Mode Gear Tilling Depth(cm) ≥10 Tilling Width(cm) 25 Blades Type 2-3/12pcs Package Dimensions(mm) 820*460*660 Loading Quantity(20GP/40HQ) 105/280 G.W(kg) 53.5
SR1Z-80B（3+1）
Rated Output/RotarySpeed(kw/r/min) 3.9/3600 Displacement(ml) 212 Fuel Tank Capacity(L) 3.6 Driving Mode Chain and Belt Tilling Depth(cm) ≥10 Tilling Width(cm) 80 Blades Type 3-4/24pcs Package Dimensions(mm) 900*460*660 Loading Quantity(20GP/40HQ) 90/258 G.W(kg) 98
SR1Z-45
Rated Output/RotarySpeed(kw/r/min) 2.8/3100 Displacement(ml) 149 Fuel Tank Capacity(L) 1 Driving Mode Gear and Belt Tilling Depth(cm) ≥10 Tilling Width(cm) 36 Blades Type 2-4/16pcs Package Dimensions(mm) 710*380*650 Loading Quantity(20GP/40HQ) 192/396 G.W(kg) 32
SR1Z-25
Rated Output/RotarySpeed(kw/r/min) 1.6/6500 Displacement(ml) 52 Fuel Tank Capacity(L) 1 Driving Mode Gear Tilling Depth(cm) ≥8 Tilling Width(cm) 25 Blades Type 2-4/16pcs Package Dimensions(mm) 520*360*460 Loading Quantity(20GP/40HQ) 305/705 G.W(kg) 17.8
