Water Pump
SRWP40D
STARTING SYSTEM Recoil Start/Electric start Displacement(ml) 418 Pump type Aluminum Max.Output(kw)/(r/min) 6.3/3600 Inler/Outlet Diameter(mm) 100/100 Suction(m) 7 Lift(m) 25 Flow(m³/h） 85 Packing Dismensions 710*560*630 G.W(kg) 67 Loading Quantity(40HQ) 256 Forced air cooling,4-Stroke,
SV,Single CylinderForced air cooling,4-Stroke,
Single Cylinder
SRWP30D
STARTING SYSTEM Recoil Start/Electric start Displacement(ml) 296 Pump type Aluminum Max.Output(kw)/(r/min) 4.0/3600 Inler/Outlet Diameter(mm) 80/80 Suction(m) 7 Lift(m) 28 Flow(m³/h） 60 Packing Dismensions 620*540*590 G.W(kg) 46 Loading Quantity(40HQ) 304 Forced air cooling,4-Stroke,
SV,Single CylinderForced air cooling,4-Stroke,
Single Cylinder
SRWP20D
STARTING SYSTEM Recoil Start/Electric start Displacement(ml) 246 Pump type Aluminum Max.Output(kw)/(r/min) 3.6/3600 Inler/Outlet Diameter(mm) 50/50 Suction(m) 7 Lift(m) 30 Flow(m³/h） 32 Packing Dismensions 500*450*530 G.W(kg) 38 Loading Quantity(40HQ) 400 Forced air cooling,4-Stroke,
SV,Single CylinderForced air cooling,4-Stroke,
Single Cylinder
SRTP30
STARTING SYSTEM Recoil Start Displacement(ml) 212 Pump type Aluminum Max.Output(kw)/(r/min) 4.3/3600 Inler/Outlet Diameter(mm) 80/80 Suction(m) 7 Lift(m) 28 Flow(m³/h） 65 Packing Dismensions 605*445*460 G.W(kg) 33 Loading Quantity(40HQ) 475 Forced air cooling,4-Stroke,
SV,Single CylinderForced air cooling,4-Stroke,
Single Cylinder
SRTP20
STARTING SYSTEM Recoil Start Displacement(ml) 212 Pump type Aluminum Max.Output(kw)/(r/min) 4.3/3600 Inler/Outlet Diameter(mm) 50/50 Suction(m) 7 Lift(m) 30 Flow(m³/h） 30 Packing Dismensions 530*440*460 G.W(kg) 30 Loading Quantity(40HQ) 550 Forced air cooling,4-Stroke,
SV,Single CylinderForced air cooling,4-Stroke,
OHV,25°Single Cylinder
SRHP30
STARTING SYSTEM Recoil Start Displacement(ml) 389 Pump type Aluminum Max.Output(kw)/(r/min) 8.0/3600 Inler/Outlet Diameter(mm) 80 Suction(m) 5 Lift(m) 80 Flow(m³/h） 30 Packing Dismensions 635*540*555 G.W(kg) 46 Loading Quantity(40HQ) 300 Forced air cooling,4-Stroke,
SV,Single CylinderForced air cooling,4-Stroke,
OHV,25°Single Cylinder
SRWP40
STARTING SYSTEM Recoil Start Displacement(ml) 212 Pump type Aluminum Max.Output(kw)/(r/min) 4.3/3600 Inler/Outlet Diameter(mm) 100/100 Suction(m) 7 Lift(m) 26 Flow(m³/h） 70 Packing Dismensions 620*465*540 G.W(kg) 31.5 Loading Quantity(40HQ) 380 Forced air cooling,4-Stroke,
SV,Single CylinderForced air cooling,4-Stroke,
OHV,25°Single Cylinder
SRHP20
STARTING SYSTEM Recoil Start Displacement(ml) 212 Pump type Aluminum Max.Output(kw)/(r/min) 4.3/3600 Inler/Outlet Diameter(mm) 40 Suction(m) 7 Lift(m) 70 Flow(m³/h） 15 Packing Dismensions 515*455*450 G.W(kg) 26 Loading Quantity(40HQ) 575 Forced air cooling,4-Stroke,
SV,Single CylinderForced air cooling,4-Stroke,
OHV,25°Single Cylinder
SRWP30
STARTING SYSTEM Recoil Start Displacement(ml) 212 Pump type Aluminum Max.Output(kw)/(r/min) 4.3/3600 Inler/Outlet Diameter(mm) 80/80 Suction(m) 7 Lift(m) 25 Flow(m³/h） 60 Packing Dismensions 535*450*460 G.W(kg) 28.5 Loading Quantity(40HQ) 550 Forced air cooling,4-Stroke,
SV,Single CylinderForced air cooling,4-Stroke,
OHV,25°Single Cylinder
SRWP20
STARTING SYSTEM Recoil Start Displacement(ml) 212 Pump type Aluminum Max.Output(kw)/(r/min) 4.3/3600 Inler/Outlet Diameter(mm) 50/50 Suction(m) 7 Lift(m) 30 Flow(m³/h） 32 Packing Dismensions 475*445*460 G.W(kg) 26 Loading Quantity(40HQ) 628 Forced air cooling,4-Stroke, SV,Single Cylinder Forced air cooling,4-Stroke, OHV,25°Single Cylinder
SRWP15
STARTING SYSTEM Recoil Start Displacement(ml) 105 Pump type Aluminum Max.Output(kw)/(r/min) 1.3/3600 Inler/Outlet Diameter(mm) 40/40 Suction(m) 7 Lift(m) 15 Flow(m³/h） 12 Packing Dismensions（mm） 360*300*385 G.W(kg) 14 Loading Quantity(40HQ) 1488 Type Forced air cooling,4-Stroke,
SV,Single Cylinder
SRWP10
STARTING SYSTEM Recoil Start Displacement(ml) 100 Pump type Aluminum Max.Output(kw)/(r/min) 1.3/3600 Inler/Outlet Diameter(mm) 40 Suction(m) 7 Lift(m) 28 Flow(m³/h） 8 Packing Dismensions（mm） 405*300*385 G.W(kg) 11 Loading Quantity(40HQ) 1290 Type Forced air cooling,4-Stroke, SV,Single Cylinder
